Resolutions:

Automatically identify the HDTV or monitor EDID by DDC channel.
Adapt to HDTV or DVI monitor automatically.
No power adaptor, no messy cords—just one HDMI cable.
Hassle Free! Plug and play.

Supported input/output Mode:

640x480@60/72/75/85Hz, 720x400@70Hz,
800x600@60/72/75/85Hz, 1024x768@60/70/75/85Hz,
1152x864@75Hz, 1280x720@60Hz,
1280x768@60/75/85Hz， 1280x800@60/75/85Hz,
1280x960@60Hz, 1280x1024@60/75Hz,
1360x768@60Hz, 1400x1050@60Hz,
1440x900@60Hz, 1600x1200@60Hz,
1680x1050@60Hz, 1920x1080@60Hz,
1920x1200_RB@60Hz, 1920x1200@60Hz

Accessories:

USB Cable--------------------------------1 PCS
VGA Cable（20cm）-------------------1 PCS
Audio Cable-------------------------------1 PCS
User Manual (EN) -----------------------1 PCS

Signal Inputs/Output

Video Input

VGA(RGBHV)

HDMI Output

compatible with HDMI 1.3

Connector

VGA/HDMI

Input Signal

RGB: 0.7 Vp-p 75 ohm

H + V

3 to 5 Vp-p

Audio Input

Analog audio L,R

Size(L-W-H)

72 x 41 x 18 mm

Weight (Net)

0.12Kg

Warranty

1 Year

Environmental

Operating Temperature

0 ℃ to +70℃

Operating Humidity

10% to 85 % RH (no condensation)

Storage Temperature

-10℃ to +80℃

Storage Humidity

5% to 90 % RH (no condensation)

Power Requirement

External Power Supply

USB Power(500mA)

Power Consumption

0.5 watts (max)

Converter Unit

FCC,CE

Accessories Adapter

DC Power Adapter

USB Cable

User Manual

English Version
