Current Position: Home >Products>Extender Series> HDMI Over Coaxial

Model:ECHS-10031PRO Input:HDMI/Coax
Output:Coax/HDMI



Main Features:
1080P to 300M HDMI 1.4 / HDCP 1.4 Dual IR bi-directional Pint This Page

Details

Features:

*Super long distance (900M): This extender can transmit 1080P HDMI video over a single standard RG6 coaxial cable. to distances upto 3937 feet (300 meters). Full HD up to 300M (RG-6U cables), HD up to 600M (RG-6U cables), SD up to 900M (RG-6U cables ), then at the receiver part from coax back to HDMI output.

*Single Link Range: 1080p/60, Lip-Sync Pass Through. Digital format in Deep Color Mode at up to 36 bits (12bits/color) and 48KHz LPCM Digital audio.
*Supports HDMI 1.2 and HDMI 1.3 with features such as 1080p, Deep Color Supported (XV Color Supported)
In/Output Support Resolution: 480i, 576i, 720p @ 50/59.94,60; 1080i @ 50/ 59.94/ 60 1080p @ 23.98/ 24/ 25/ 29.97/ 30/ 50/ 59.94/ 60

*Dual IR Control: The wide-bands IR blaster allows you to control your video source device and also sink devices using its IR remote control from the remote location


Specification:

Input power standard 5V
Consumption 3W
HDMI port HDMI-A female
Coaxial port BNC
Connection Coaxial cable
Transmission up to 300m
Resolution supported 1080p@60Hz/ 1080p@50Hz/ 1080p@30Hz/
1080p@25Hz/ 720p@60Hz/ 720p@50Hz/ 480@60Hz
Operation Temperature -20℃ ~70℃
Storage Temperature -40℃ ~80℃
Humidity 20% ~ 90% RH（Non-consider）
